Prvi Android video-interfon na svijetu sa Starlight kamerom
Akuvox X916 SIP video-interfon je jedan od najmoćnijih modela u industriji, koji integriše najnovije tehnologije uključujući Starlight kameru, HDR, Android 9.0 i prepoznavanje lica. Najčešće se koristi u luksuznim stambenim i poslovnim zgradama.
Dvostruki mikrofon sa mogućnošću prijema zvuka do 5 metara i vrhunskom tehnologijom za smanjenje buke.
Pokretan Android 9.0 operativnim sistemom, X916 je lakši za upotrebu, sa više korisnih funkcija i opcija prilagođavanja, dok u isto vrijeme nudi poboljšanu zaštitu privatnosti.
Dvostruki mikrofon sa mogućnošću prijema zvuka do 5 metara i vrhunskom tehnologijom za smanjenje buke.
Pokretan Android 9.0 operativnim sistemom, X916 je lakši za upotrebu, sa više korisnih funkcija i opcija prilagođavanja, dok u isto vrijeme nudi poboljšanu zaštitu privatnosti.
- Vandalo otporno kućište sa 13-inčnim ekranom na dodir
- Operativni sistem Android
- Širokougaona kamera: 115° (H), 63° (V)
- Dvosmjerna audio komunikacija preko IP mreže sa funkcijom poništavanja buke (Echo Cancel)
- Višestruki načini pristupa uključujući: lice, karticu, PIN, BLE i QR kod
- Ugradnja u zid i na zid
- U skladu sa SIP i ONVIF standardima
Obezbjeđuje kontrolu pristupa stanarima i posjetiocima u objektima kao što su stambene zgrade, poslovne zgrade, zatvorene zajednice i industrijski objekti
- Podržava više metoda autentifikacije – praktično za različite tipove korisnika
- Otporan na spoljašnje uticaje – pogodan za vanjsku instalaciju
- Brzo prepoznavanje lica
- Kompatibilan sa bezbjednosnim i sistemima kontrole pristupa
- Jednostavna integracija u IP infrastrukturu
Supports multiple access methods — convenient for different categories of users;
Resistant to external factors — suitable for outdoor installation;
High-speed face recognition;
Compatible with security and access control systems;
Easy integration into IP infrastructure.
Resistant to external factors — suitable for outdoor installation;
High-speed face recognition;
Compatible with security and access control systems;
Easy integration into IP infrastructure.
Dual MICs with 5-meter sound pickup capability and excellent noise reduction technology.
Running on Android 9.0, X916 is easier to use with more helpful features and customization, while offering better privacy improvement.
Running on Android 9.0, X916 is easier to use with more helpful features and customization, while offering better privacy improvement.
Akuvox X916
X916S
X916S-L
Physical & Power
Front panel
316 grade stainless steel
316 grade stainless steel
Display
13 Inch IPS LCD
13 Inch IPS LCD
Main Camera
2M pixels, with Starlight
2M pixels, with Starlight
Auxiliary Camera 1
2M pixels
2M pixels
Auxiliary Camera
0.3M pixels
0.3M pixels
Light sensor
FDD LTE Bands
B1, B3, B7, B8, B20, B28A
Motion sensor
Wiegand port
RS485 port
RF card reader
13.56MHz & 125kHz, NFC
13.56MHz & 125kHz, NFC
Micro SD card slot
Relays out
4
4
Inputs
4
4
Reset button
USB interface
2
2
HDMI interface
1
1
TF card slot
1
1
BLE
Tamper alarm
Microphone
2
2
Speaker
2
2
Power out
12V/500mA (Max.)
12V/500mA (Max.)
Ethernet port
2xRJ45, 10/100/1000Mbps adaptive
2xRJ45, 10/100/1000Mbps adaptive
PoE
802.3at Power-over-Ethernet+
802.3at Power-over-Ethernet+
Power
12~24V DC connector (if not using PoE+)
12~24V DC connector (if not using PoE+)
IP & IK rate
IP65 & IK07
IP65 & IK07
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Dimension
383.9x339.15x45.8mm
383.9x339.15x45.8mm
Working humidity
10~90%
10~90%
Working temperature
-20°C ~ +55°C
-20°C ~ +55°C
Storage temperature
-40°C ~ +70°C
-40°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.8”, CMOS for main camera
1/2.8”, CMOS for main camera
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
H.264
Video technology
HDR
HDR
Video resolution
up to 1920x1080p
up to 1920x1080p
Max. image transfer rate
1080p – 30fps
1080p – 30fps
Viewing angle
115°(H) / 63°(V)
115°(H) / 63°(V)
Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Individually by DTMF tones
Multi-way unlock
Face, IC/ID Card, PIN, QR code and BLE
Face, IC/ID Card, PIN, QR code and BLE
Camera
Permanently operational
Permanently operational
Auto-night mode
with LED illumination
with LED illumination
White balance
Auto
Auto
Minimum illumination
0.1LUX
0.1LUX
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
