Akuvox A01
209
€
€
Add to basket
Smart, Compact, and Stylish Access Control Terminal
Akuvox's AO1S access control terminal incorporates door controller and an RIFD reader in one standalone device, thus saving your solution costs. Equipped with an RFID reader ( 125kHz and 13.56MHz) which is capable of handling a majority of cards in wide use currently. AO1S is designed to provide you with greater flexibility and security than those traditional access control systems.
A01 requires less wiring and installation effort thanks to its PoE support and a Wiegand interface and can be easily configured and maintained via a web user interface.
Akuvox A01
A01S
Physical & Power
Front panel
Toughened Glass
Frame
Alluminium Alloy
RFID card reader
13.56MHz & 125kHz
Relays out
1
Inputs
2
Wiegand port
Speaker
1
Tamper proof alarm
Ethernet port
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
IP & IK rate
IP65 & IK07
Installation
Wall-mounted & Flush-mounted
Dimension
86x86x33mm
Working humidity
10~90%
Working temperature
-20°C ~ +55°C
Storage temperature
-30°C ~ +70°C
Door Entry Feature
Access schedule
Access level management
Support switch to reader mode
Door access logs
Flexible shift scheduling and attendance management
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
Akuvox A01S Datasheet V2.0
Akuvox A01 Smart Terminal Access Control Cutsheet
