Akuvox A03
295
€
€
Add to basket
Perfect choice for Access Control
Akuvox’s A03S is a safe and convenient commercial-grade device for access control. It offers you a BLE feature that enables you to open door via credential on your smartphone. And it can be easily connected to a PoE using an Ethernet cable for data transmission. A03S provides you with greater security and flexibility than those traditional access control systems.
Supporting PoE, A03 only requires a network cable
for installation. With a compact size, it is perfect for
buildings with limited installation space.
Akuvox A03
A03S
Physical & Power
Front panel
Toughened Glass
Frame
Alluminium Alloy
RFID card reader
13.56MHz & 125kHz
BLE
Relays out
1
Inputs
2
Wiegand port
Speaker
1
Tamper proof alarm
Ethernet port
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
IP & IK rate
IP65 & IK07
Installation
Wall-mounted & Flush-mounted
Dimension
86x86x33mm
Working humidity
10~90%
Working temperature
-20°C ~ +55°C
Storage temperature
-30°C ~ +70°C
Door Entry Feature
Access schedule
Access level management
Support switch to reader mode
Door access logs
Flexible shift scheduling and attendance management
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
Akuvox A03S Datasheet V2.0
Akuvox A03 Smart Terminal Access Control Cutsheet
