Perfect choice for Access Control
Akuvox’s A05C is a safe and convenient commercial-grade device for access control. With the latest deep learning algorithm and dual IR camera liveness detection technology, A05C can be deployed in the field for community and commercial applications, for the implementation of smart access control.
- Plastic body with 5inch display;
- Visible light facial recognition;
- Anti-spoofing algorithm against photo and video attack;
- Wide-angle camera: 62º (H), 36º (V);
- 20,000 face capacity & 20,000 card capacity;
- Multi-way access feature including: Face, Card, BLE & QR code;
- Surface-mounted;
- Mask Detection;
- Body Temperature Detection (Only A05C(MD01) & A05C(MD02) support)
A05C offers fast, safe and reliable access control via face recognition, which adapts to your facial changes over time.
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs
???????????????????
Face recognition, mobile access, temperature measurement, and mask detection in one device.
Akuvox A05C
A05C
Physical & Power
Housing Material
Plastic
Display
5 Inch IPS LCD
Camera
2M pixels, WDR
Wiegand port
RS485
RF card reader
13.56MHz, NFC
BLE
Relays out
1
Inputs
1
Tamper proof alarm
Ethernet port
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
IP & IK rate
IP65 & IK07
Installation
Wall-mounted & Flush-mounted
Dimension
192x88x23.8mm
Working humidity
10~90%
Working temperature
-20°C ~ +60°C
Storage temperature
-30°C ~ +70°C
Indetification
Identification Mode
Face, NFC, RFID Card, BLE & QR code
Identification Speed
<200ms
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
Temperature Measurement
Support
Only A05C(MD02)
Distance
0.3M ~ 1M
Accuracy
0.1℃
Deviation
±0.3℃
Range
34℃ ~ 45℃
Wrist Temperature Measurement
Support
Only A05C(MD01)
Distance
1cm ~ 5cm
Accuracy
0.1℃
Deviation
±0.3℃
Range
34℃ ~ 45℃
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
