Perfect Access Control for your premise
Akuvox’s A08 is a slim access control terminal that combines door controller and
card reader in one device saving much cost for building operators. It offers
flexible credentials, including PIN code, QR scanning, wave-to-unlock via
Bluetooth, mobile access via NFC and RFID cards.
card reader in one device saving much cost for building operators. It offers
flexible credentials, including PIN code, QR scanning, wave-to-unlock via
Bluetooth, mobile access via NFC and RFID cards.
- Aluminum alloy frame with toughened glass;
- IP65 & IK09;
- 20,000 card capacity & 100,000 Event Log;
- Multiple access methods: QR Code, Bluetooth, PIN, RFID;
- Flush mounted & surface mounted;
- Supports Wiegand & OSDP protocol
Despite its slim profile, the A08 offers four types of door unlocking options, providing users with a seamless and convenient experience catered to diverse user preferences
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs
????????????????????/
The slimline profile makes the A08 adaptable to a range of spaces. It can fit discreetly into narrow space such as a door frame or a stand, optimizing space utilization while providing ease of installation.
Akuvox A08
A08K
A08S
A08S HID Prox
A08S HID iClass
Physical & Power
Front panel
Toughened Glass
Toughened Glass
Toughened Glass
Toughened Glass
Frame
Aluminum Alloy
Aluminum Alloy
Aluminum Alloy
Aluminum Alloy
RFID card reader
13.56MHz & 125kHz
13.56MHz & 125kHz
HID Prox 125kHz
HID iClass 13.56MHz
Relays out
1
1
1
1
Inputs
2
2
2
2
Wiegand port
RS485 port
BLE
QR code
Speaker
8Ω / 0.5W
8Ω / 0.5W
8Ω / 0.5W
8Ω / 0.5W
Tamper proof alarm
Ethernet port
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Power out
12V 600mA
12V 600mA
12V 600mA
12V 600mA
IP & IK rate
IP65 & IK09
IP65 & IK09
IP65 & IK09
IP65 & IK09
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Dimension
50x140x26.7mm
50x140x26.7mm
50x140x26.7mm
50x140x26.7mm
Working humidity
10~90%
10~90%
10~90%
10~90%
Working temperature
-20°C ~ +55°C
-20°C ~ +55°C
-20°C ~ +55°C
-20°C ~ +55°C
Storage temperature
-30°C ~ +70°C
-30°C ~ +70°C
-30°C ~ +70°C
-30°C ~ +70°C
Door Entry Feature
Access schedule
Access level management
Support switch to reader mode
Door access logs
Flexible shift scheduling and attendance management
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
Akuvox Cloud management
Akuvox SDMC & ACMS
