Reliable access controller for your building
The Akuvox A094S is a 4-door access controller with Ethernet interface. It supports 50,000 users and various functions that enable you to control who comes into your building. And the tamper proof design makes that more secure and reliable.
- Stylish appearance;
- Linux operation system;
- Supports RS485, Wiegand protocol for accessing card readers;
- Supports TCP/IP communication and web interface for management;
- Supports up to 50,000 users and 100,000 logs presenting records;
- Supports anti-pass back function & emergency door release (EDR);
- Support tamper proof alarm;
- Wall-mounted
- Easy to establish large-scale access control system with Akuvox ACMS;
A094 centralizes user data and access credentials when working standalone and can be easily configured and maintained via a browser.
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs
???????????????????
Akuvox A094S
A094S
Physical & Power
Front panel
SGCC
Power input
100～240VAC/1.5A 50/60Hz
Wiegand port
4
Relays out
8
Inputs
13
RS485 port
4
Communication
TCP/IP
Wiegand
26/34
Power output
4
Ethernet port
RJ45, 10/100Mbps adaptive
Tamper proof alarm
Status lights
Installation
Wall-mounted
Dimension
365x340x85 mm
Working humidity
10~90%
Working temperature
-10°C ~ +55°C
Storage temperature
-20°C ~ +70°C
Door Entry Feature
User storage
50.000
Anti-pass back function
Multi-door interlock function
Access table export & import
Access level management
Door access logs query and export
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, TFTP, DNS, SNTP, TCP, UDP, TLS, ICMP, DHCP, ARP
Card Readers
Wiegand 26/34/58 readers
RS485 readers
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs
