Reliable access controller for your building
The Akuvox A095S is a 4-door access controller with Ethernet interface. It supports 100,000 users and various functions that enable you to control who comes into your building. And the tamper proof design makes that more secure and reliable.
- Stylish appearance;
- Linux operation system;
- Supports RS485, Wiegand protocol for accessing card readers;
- Supports TCP/IP communication and web interface for management;
- Supports up to 100,000 users and 200,000 logs presenting records;
- Supports multi-door unlock, anti-pass back function & first person in;
- Support Wi-Fi and LTE;
- Wall-mounted & DIN rail
- Easy to establish large-scale access control system with Akuvox ACMS;
A095 centralizes user data and access credentials when working standalone and can be easily configured and maintained via a browser.
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs
- Work with Akuvox Cloud & ACMS
???????????????????
Akuvox A095
A095S
Physical & Power
Front panel
Plastic
Power input
12VDC / 5A
Wiegand port
8
Relays out
8
Inputs
12
RS485 port
8
Power output
8
WiFi
IEEE 802.11a/b/g/n/ac/ax, 2.4GHz & 5GHz
LTE
Optional
SIM card slot
Optional
TF card slot
1
Ethernet port
2xRJ45, 10/100Mbps adaptive
PoE
802.3at Power-over-Ethernet
Reset
Status lights
Installation
Wall-mounted & DIN Rail
Dimension
208x128.5x37 mm
Working humidity
10~90%
Working temperature
-10°C ~ +55°C
Storage temperature
-20°C ~ +70°C
Door Entry Feature
Anti-pass back function
Multi-door interlock function
First person in function
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, TFTP, OSDP, DNS, SNTP, TCP, UDP, TLS, ICMP, DHCP, ARP
Card Readers
Wiegand 26/34/58 readers
RS485 readers, OSDP/OSDP V2
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs
Akuvox cloud & ACMS
