Reliable access controller for your building
The Akuvox EC33 is an IP elevator controller which uses HTTP
commands to communicate with other Akuvox devices. Each
controller has 32 outputs and can expand to 128 outputs.
commands to communicate with other Akuvox devices. Each
controller has 32 outputs and can expand to 128 outputs.
- 10/100M Ethernet;
- Large storage for 20,000 card and 100,000 logs;
- EC33 supports 32 outputs an can connect to an expansion controller to expand to 128 outputs;
- RS485 port to connect to a expansion controller;
- Fire Alarm input to support emergency door release or normal lift commands;
- Works with other Akuvox devices by using HTTP commands;
- Akuvox Cloud supported;
Thanks to the integration with Akuvox intercoms, the moment residents and visitors gain access at the building entrance via an Akuvox door phone, EC33 will send the elevator to the first floor for them, saving their waiting time.
????????????????
???????????????????
Akuvox EC33
EC33
Physical & Power
Communication
TCP/IP
RS485
Relays out
32
Wiegand
26/34
Ethernet port
RJ45, 10/100Mbps adaptive
Fire alarm input
1
Power
100～ 240VAC Input (if not using PoE)
PoE
802.3af Power-over-Ethernet
Rated power
≤ 10W
Installation
Wall-mounted
Dimension
320x270x75 mm
Working humidity
10~90%
Working temperature
<45℃
