Single-button SIP doorbell Akuvox DB01
The perfect indoor video doorbell for everyday life.
Reliable security that comes with the ability to control who enters your apartment and the ability to verbally and visually confirm your identity. The Akuvox DB01 call panel alerts you to a doorbell and allows you to see and talk to visitors from your smartphone, wherever you are.
Reliable security that comes with the ability to control who enters your apartment and the ability to verbally and visually confirm your identity. The Akuvox DB01 call panel alerts you to a doorbell and allows you to see and talk to visitors from your smartphone, wherever you are.
- One button for indoor operation;
- Linux operating system;
- Wide-angle camera: 136°(W) / 90°(H);
- Real-time two-way audio;
- Wall mounting;
- Support SlP and ONVlF.
Individual apartment video doorbell
- Automatic initialization
- Web interface management
- Network traffic analysis
- Backup/restore settings
- Export access log
- Export/Import access list
- Firmware update
- System log (including access log)
- High-resolution wide-angle camera — provides clear visuals of visitors
- Real-time two-way audio — enables direct communication from anywhere via smartphone
- Linux-based system — ensures stability and reliability
- Supports SIP and ONVIF — allows integration with various IP systems
- Web interface management — simplifies setup and maintenance
- Compact one-button design — ideal for single-apartment installations
Akuvox DB01
DB01
Physical & Power
Front Panel
Plastic
Display
Camera
2M pixels, automatic lighting
Light Sensor
Infrared sensor
Button
1 call button with backlight
Wiegand port
RS485 port
RF card reader
Micro SD card slot
Relays Out
1
Inputs
1
BLE
Wi-Fi
ONVIF
LTE
Microphone
1
Speaker
1
Ethernet port
1xRJ45, 10/100Mbps adaptive
PoE
PoN
Powered from Akuvox monitor
Power
DC12V / 1A (if not using PoN)
IP & IK rate
Installation
Wall-mounted
Dimension
146x70x23mm
Working Humidity
10~90%
Working Temperature
-20°C ~ +55°C
Storage Temperature
-40°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
Broadband audio codec
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo Cancellation
Voice Activation Detection
Comfort Noise Generator
Video
Sensor
1/2.7”, CMOS
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
Video resolution
up to 1920x1080p
Max. image transfer rate
1080p – 25fps
Viewing angle
136°(H) / 90°(V)
LED
White LEDs for picture lighting during dark hours with internal light sensor
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Camera
Permanently operational
Auto-night mode
with LED illumination
White balance
Auto
Minimum illumination
0.1LUX
Deployment & Maintenance
Auto-Provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
