Feature-rich and Stylish Entry-Level Door Phone
The Akuvox E13S is a single-button SIP video door phone designed for mid-range residential buildings. It is a perfect blend of sleek design, rich intercom functionality, and ease of installation.
The E13S boasts smooth lines and a symmetrical design which provide a sence of visual balance and minimalist beauty. Despite its compact form, it features crystal-clear audio quality, access control capabilities, and app-based control, delivering both convenience and security.
Equipped with a 2MP camera featuring 1080p resolution and WDR technology the E13S ensures exceptional video clarity, even in challenging lightning conditions, so you always know what's happening at your doorstep.
Designed for easy installation, it fits neatly into a standard single-gang box with minimal wall protrusion or can be wall-mounted using a standard 86 type electrical box.
Rated IP65 and operational in temperatures ranging from -40°C to +60°C, the E13S is ready to withstand diverse outdoor environments.

Equipped with a 2MP camera featuring 1080p resolution and WDR technology the E13S ensures exceptional video clarity, even in challenging lightning conditions, so you always know what's happening at your doorstep.
Akuvox E13
E13S
E13N
Physical & Power
Body material
Plastic
Plastic
Display
4 Inch, color TFT LCD, touchable
4 Inch, color TFT LCD, touchable
Camera
2M pixels, automatic lightning
2M pixels, automatic lightning
Button
1 call button
1 call button
Wiegand port
1ch input/output (selectable)
1ch input/output (selectable)
RF card reader
13.56MHz & NFC (only Android)
Light sensor
Relays out
1
1
Inputs
2
2
Microphone
Speaker
Ethernet port
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
Tamper alarm
PoE
802.3af Power-over-Ethernet
Power-over-Network
Power
12V DC connector(if not using PoE)
12V DC connector(if not using PoN)
IP & IK rate
IP65
IP65
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Dimension (wall-mounted)
160x86x25mm
160x86x25mm
Dimension (flush-mounted)
160x86x25mm
160x86x25mm
Working humidity
10~90%
10~90%
Working temperature
-40°C ~ +60°C
-40°C ~ +60°C
Storage temperature
-40°C ~ +70°C
-40°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ
G.711a, G.711μ
Wireband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.8”, CMOS
1/2.8”, CMOS
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
H.264
Video resolution
up to 1920x1080p
up to 1920x1080p
Max. image transfer rate
1080p – 30fps
1080p – 30fps
Viewing angle
114°(H) / 58°(V)
114°(H) / 58°(V)
LED
IR LEDs for picture lighting during dark hours
IR LEDs for picture lighting during dark hours
Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Individually by DTMF tones
Camera
Permanently operational
Permanently operational
Auto-night mode
Auto-night mode with IR LED illumination
Auto-night mode with IR LED illumination
White balance
Auto
Auto
Minimum illumination
0.1LUX
0.1LUX
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
