Akuvox E18C
963
Face recognition doorphone featuring touchless building access, wireless communication and hassle-free management.
Akuvox E18C is a smart IP video door phone for secure access control in residential and commercial settings. It features a 7-inch touchscreen and advanced face recognition for fast, contactless entry — even when wearing masks — with >99.5% accuracy and <0.2s response time.
Along with face ID, E18C supports RFID (13.56 MHz & 125 kHz), NFC, Bluetooth (BLE), PIN codes, and QR codes. It integrates easily into IP-based systems via SIP and ONVIF, and offers two-way audio with echo and noise cancellation.
Connectivity includes RJ45 with PoE, optional LTE, and interfaces such as Wiegand, RS485, relays, and inputs. It supports temperature screening and mask detection (with external sensor) and is IP65-rated for outdoor use.
With detailed logs, remote management, and flexible mounting options, E18C is a powerful, all-in-one access control solution.
Introducing Akuvox E18 smart door phone, a versatile and powerful door phone with a 7-inch touchscreen, touchless access options, and an optional 4G module for wireless communication.
Akuvox E18
E18C
E18C-LTE
Physical & Power
Front panel
Plastic
Plastic
Display
7 Inch IPS LCD, 1024x600
7 Inch IPS LCD, 1024x600
Camera
2M pixels, WDR
2M pixels, WDR
Wiegand In
1
1
Wiegand Out
1
1
Reset
1
1
RS485 port
RF card reader
13.56MHz,125kHz & NFC
13.56MHz,125kHz & NFC
TF card slot
1
1
Relays out
2
2
Relays in
3
3
Bluetooth
Tamper alarm
Ethernet port
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE+)
12V DC connector (if not using PoE+)
IP & IK rate
IP65
IP65
Installation
Wall-mounted
Wall-mounted
Dimension (wall-mounted)
275x120x34.6mm
275x120x34.6mm
Working humidity
10~90%, no condensing
10~90%, no condensing
Working temperature
-20℃~+55℃
-20℃~+55℃
Storage temperature
-30℃~+60℃
-30℃~+60℃
Identification
Identification Mode
Face, PIN, NFC, RFID Card, BLE & QR code
Face, PIN, NFC, RFID Card, BLE & QR code
Identification Speed
<200ms
<200ms
Forehead Temperature Measurement
Only E18C (MD02) support (distance: 0.3M ~ 1M, accuracy: 0.1℃, range: 34℃ ~ 45℃)
Only E18C (MD02) support (distance: 0.3M ~ 1M, accuracy: 0.1℃, range: 34℃ ~ 45℃)
