Axuvox R25A
2338
Single-button SIP video door phone that perfectly combines security, style, and functionality.
Akuvox R25A is a compact, single-button SIP video door phone tailored for residential properties, seamlessly blending security, style, and functionality. It features a wide-angle camera with a fisheye lens that supports resolutions up to 2K, delivering superior video clarity and coverage of up to 150° horizontally and vertically. Housed in a rugged aluminum-alloy body rated IP65, the R25A is suitable for outdoor use. The device supports versatile access methods, including RFID (13.56 MHz & 125 kHz), NFC, and PIN code entry, with dual relay outputs, Wiegand, RS485, and two input ports for flexible system integration. Equipped with two-way audio featuring echo cancellation, and compatible with SIP and ONVIF protocols, the R25A ensures clear communication and easy integration into IP-based systems. It supports PoE (IEEE 802.3af) or 12 V DC power input and can be installed either surface- or flush-mounted. Additional features include an illuminated backlit button, auto night mode with LED lighting, auto white balance, voice activation detection, comfort noise generation, and comprehensive system logs.
Akuvox R25A is a compact IP video doorphone designed for secure access control in residential and commercial environments. It features a 2MP wide-angle camera with infrared night vision, supports RFID (13.56 MHz & 125 kHz), NFC, and PIN code access, and offers two-way audio with echo cancellation. Housed in a durable IP65-rated aluminum alloy body, the R25A integrates easily into IP systems via SIP and ONVIF and supports PoE or 12V DC power, making it ideal for outdoor installations with limited space.


Akuvox R25A
R25A
Physical & Power
Front panel
Aluminum alloy
Button
1
Camera
4M pixels, automatic lighting
Light sensor
Infrared Sensor
Wiegand port
RS485 port
RF card reader
13.56MHz & 125kHz, NFC
Relays out
2
Inputs
2
Microphone
1
Speaker
1
Ethernet port
1xRJ45, 10/100Mbps adaptive
PoE
802.3af PoE
Tamper alarm
IP & IK rate
IP65
Installation
Wall-mounted & Flush-mounted
Dimension (wall-mounted)
145x85x24.8mm
Dimension (flush-mounted)
145x85x24.8mm
Working humidity
10~90%
Working temperature
-40°C ~ +55°C
Storage temperature
- 40°C~ + 70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
Wideband audio codec
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/3.2”, CMOS
Pixels
CIF, VGA, 4CIF, 720p, 1080p, 2K
Video codec
H.264
Video resolution
up to 2000x2000
Max. image transfer rate
2K – 30fps
Viewing angle
150°(H) / 150°(V)
Compatible to 3rd-Party-Video components, e.g. NVRs
High intensity IR LEDs for picture lighting during dark hours with internal light sensor
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Camera
Permanently operational
White balance
Auto
Minimum illumination
0.1LUX
Auto- night mode with LED illumination
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
