World's First Facial Recognition Android Doorphone
Akuvox R29 is the world’s first Android-based video door phone with built-in offline face recognition, featuring a 7-inch touchscreen and modern access control capabilities. Designed for upscale residential buildings, office complexes, and multi-dwelling units, the R29 combines elegant aesthetics with cutting-edge security. It supports fast and reliable facial recognition processed locally on the device, ensuring user privacy and reducing latency. The R29 series comes in multiple variants to fit different project needs: the standard model (R29S), a dual-camera version with Bluetooth (R29C), a temperature-checking model (R29C‑B), an LTE-enabled version (R29C‑L), and one with a fingerprint reader (R29C‑T). This flexibility allows seamless adaptation to a wide range of environments and security requirements. As a SIP-based video intercom, the R29 enables high-quality video and audio communication and keypad-based access control. It supports PoE or 12 V DC power input and offers both surface and flush mounting options, making it a versatile solution for modern access control systems.
Akuvox R29 is a high-performance IP video intercom designed for advanced access control in residential and commercial buildings. It combines intelligent facial recognition, multi-method authentication, and SIP-based communication, offering a modern and secure solution for seamless integration into IP access control systems.
Akuvox R29
R29S
R29C
R29CT
R29C-L
Physical & Power
Front panel
Aluminum
Aluminum
Aluminum
Aluminum
Display
7 Inch IPS LCD capacitive touch screen
7 Inch IPS LCD capacitive touch screen
7 Inch IPS LCD capacitive touch screen
7 Inch IPS LCD capacitive touch screen
Camera
2M pixels, automatic lighting
2M pixels, automatic lighting
3M pixels, automatic lighting
2M pixels, automatic lighting
Auxiliary Camera
1M pixels
1M pixels
1M pixels
Light sensor
Motion sensor
Infrared sensor
Wiegand port
RS485 port
RF card reader
13.56MHz & 125kHz, NFC (only Android)
13.56MHz & 125kHz, NFC (only Android)
13.56MHz & 125kHz
13.56MHz & 125kHz
Relays out
3
3
3
2
Relays ln
3
3
3
2
Microphone
-32dB
Speaker
8Ω / 2W
BLE
Tamper alarm
Ethernet port
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
PoE
IEEE 802.3at PoE
IEEE 802.3at PoE
IEEE 802.3af PoE+
Power
12V DC (if not using PoE)
12V DC (if not using PoE)
12V DC (if not using PoE)
12V DC connector
IP & IK rate
IP65 & IK06
IP65 & IK06
IP65
IP65
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Wall-mounted
Dimension (wall-mounted)
324x130x27mm
324x130x27mm
324x130x33mm
324x130x33mm
Dimension (flush-mounted)
324x130x60mm
324x130x60mm
324x130x60mm
Working humidity
10~90%
10~90%
10~90%
10~90%
Working temperature
-20°C - +55°C
-20°C - +55°C
-20°C - +55°C
-20°C - +55°C
Storage temperature
-40°C - +70°C
-40°C - +70°C
-40°C - +70°C
-40°C - +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ
G.711a, G.711μ
G.711a, G.711μ
G.711a, G.711μ
Wideband audio codec
G.722
G.722
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.8”, CMOS
1/2.8”, CMOS
1/3”, CMOS
1/2.8”, CMOS
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
H.264
H.264
H.264
Video resolution
up to 1920x1080p
up to 1920x1080p
up to 1920x1080p
up to 1920x1080p
Max. image transfer rate
1080p - 25fps
1080p - 25fps
1080p - 25fps
1080p - 25fps
Viewing angle
105(H)/55°(V)
105(H)/55°(V)
120°(H) / 64°(V)
105(H)/55°(V)
High intensity IR LEDs for picture lighting during dark hours with internal light sensor
White LEDs for QR code scanning
Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Network connection
LTE-FDD
B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28
LTE-TDD
B38/B39/B40/B41
WCDMA
B1/B2/B4/B5/B6/B8/B19
Door Entry Feature
Android OS for any 3rd-party software or customization
Relays controlled
Individually by DTMF tones
Individually by DTMF tones
Individually by DTMF tones
Individually by DTMF tones
Multi-way Unlock
EM/Mifare Card, PIN, QR and BLE
Face, EM/Mifare Card, PIN, QR and BLE
Face, EM/Mifare Card, PIN, QR and BLE
Face, EM/Mifare Card, PIN, QR and BLE
Camera
Permanently operational
Permanently operational
Permanently operational
Permanently operational
Auto-night mode with LED illumination
White balance
Auto
Auto
Auto
Auto
Minimum illumination
0.1LUX
0.1LUX
0.1LUX
0.1LUX
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
