Axuvox S539
2338
Vandal-resistant Door Phone for High-end Buildings
Akuvox S539 is a high-end video door phone designed for modern buildings with advanced security and access needs.
It supports multiple authentication methods, including face recognition, RFID (13.56 MHz & 125 kHz), PIN code, BLE, NFC, and QR codes — with support for multi-factor access.
The device features a 10-inch touchscreen, a 5 MP HDR starlight camera with a dedicated QR lens, and dual microphones with echo cancellation.
Its durable aluminum and stainless-steel housing is IP66 and IK08 rated, ideal for outdoor use.
S539 runs on Android OS, integrates easily via SIP and ONVIF, and offers PoE+ or 12–24 V DC power. With Wiegand, RS485, multiple relays, and cloud-ready features, it delivers secure and flexible access control for smart environments.
Akuvox S539 is a high-performance IP video intercom designed to deliver advanced access control for premium residential and commercial properties. It combines cutting-edge technology, robust construction, and versatile features to ensure enhanced security, seamless integration, and a user-friendly experience.
Akuvox S539
S539
Physical & Power
Front panel
Aluminum
Display
10 Inch IPS LCD
Camera
5M pixels, with starlightLight Sensor
Light sensor
SupportToF Sensor
SupportMotion Sensor
SupportLine Out
Reset Button
1
Wiegand port
RS485 port
RF card reader
13.56MHz & 125kHz, NFC
Relays out
3
BLE
Wi-Fi
ONVIF
LTE
Microphone
2
Speaker
2
Ethernet port
1xRJ45, 10/100Mbps adaptive
PoE
IEEE 802.3at PoE+
Power
DC12V / 3A or DC24V / 1.5A
IP & IK rate
IP66 & IK08
Installation
Wall-mounted & Flush-mounted
Dimension (wall-mounted)
367.5x183x35.5mm
Dimension (flush-mounted)
363.5x179.8x64mm
Working humidity
10~90%
Working temperature
-30°C ~ +55°C
Storage temperature
-30°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
Wideband audio codec
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.7”, CMOS for main camera
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
Video resolution
up to 1920x1080p
Max. image transfer rate
1080p – 30fps
Viewing angle
120°(H) / 72°(V)
Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Multi-way unlock
Face, Card, PIN, BLE & QR code
Camera
Permanently operational
White balance
Auto
Minimum illumination
0.1LUX
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
