Vandal-resistant Door Phone for High-end Buildings
Akuvox X912 is a flagship door phone designed for facilities with high demands on security and functionality.
The device supports multiple identification methods, including face recognition, RFID, PIN code, BLE, and QR codes, providing flexible and secure access control.
The unit features a durable metal housing with high protection ratings against water and vandalism (IP65, IK10), making it an ideal solution for outdoor installation.
Equipped with an HDR-enabled camera, a touchscreen display, and two-way audio communication, the device ensures convenient and intuitive user interaction. It integrates easily into IP systems, supports the SIP protocol, offers PoE+ power supply, and enables door lock control.
The device supports multiple identification methods, including face recognition, RFID, PIN code, BLE, and QR codes, providing flexible and secure access control.
The unit features a durable metal housing with high protection ratings against water and vandalism (IP65, IK10), making it an ideal solution for outdoor installation.
Equipped with an HDR-enabled camera, a touchscreen display, and two-way audio communication, the device ensures convenient and intuitive user interaction. It integrates easily into IP systems, supports the SIP protocol, offers PoE+ power supply, and enables door lock control.
- 4-inch color TFT LCD touchscreen display;
- Vandal resistant body with physical or piezo keypad;
- Linux operating system;
- 2 MP HDR camera with a 125° (H) / 65° (V) field of view;
- Two-way audio communication over IP networks with Echo Cancel feature;
- 1 × RJ45 (Ethernet) port supporting high-speed network connectivity;
- Wiegand and RS485 interfaces for seamless third-party system integration;
- Gesture detection sensor;
- 2 output relays and 3 input ports;
- Flush-mounted & surface-mounted;
- Support SlP and ONVlF;
- Powered via PoE+ (IEEE802.3at) or 12–24 V DC;
- Multi-way access feature including: Face recognition (>99% accuracy, <0.6s), RFID (13.56 MHz & 125 kHz), PIN code, Bluetooth (BLE), QR code.
Provides resident / visitor access control for buildings such as condominiums, apartment buildings, office buildings, gated communities and industrial buildings.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Export access log;
- Export/Import access list;
- Firmware update;
- System log (including access log).
Supports multiple access methods — convenient for different categories of users; Resistant to external factors — suitable for outdoor installation; High-speed face recognition; Compatible with security and access control systems; Easy integration into IP infrastructure.
Akuvox X912 is a high-tech IP video intercom designed to provide reliable access control in high-end residential and commercial buildings. The device combines advanced technology, durable construction, and a wide range of features to ensure security and user convenience.
Akuvox X912
X912S
X912K
Physical & Power
Front panel
Stainless steel
Aluminum
Display
4 Inch, color TFT LCD, touchable
4 Inch, color TFT LCD, touchable
Camera
2M pixels
2M pixels
Light sensor
Infrared sensor
Gesture detection sensor
Button
Piezoelectric keypad
Physical numeric keypad
Wiegand port
RS485 port
RF card reader
13.56MHz & 125kHz, NFC
13.56MHz & 125kHz, NFC
Micro SD card slot
Relays out
2
2
Inputs
3
3
BLE
Wi-Fi
ONVIF
Line out
1
1
LTE
Tamper alarm
Microphone
-42dB
-42dB
Speaker
8Ω / 2W
8Ω / 2W
Ethernet port
RJ45, 10/100Mbps adaptive
RJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power out
DC12V / 1A (max)
DC12V / 1A (max)
Power
12V DC connector (if not using PoE+)
12V DC connector (if not using PoE+)
IP & IK rate
IP65 & IK10
IP65 & IK08
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Dimension (wall-mounted)
234x94.5x34mm
234x94.5x34mm
Dimension (flush-mounted)
264x115.6x45mm
264x115.6x45mm
Working humidity
10~90%
10~90%
Working temperature
-20°C ~ +60°C
-20°C ~ +60°C
Storage temperature
-40°C ~ +70°C
-40°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.8”, CMOS for main camera
1/2.8”, CMOS for main camera
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
H.264
Video resolution
up to 1920x1080p
up to 1920x1080p
Max. image transfer rate
1080p – 30fps
1080p – 30fps
Viewing angle
125°(H) / 65°(V)
125°(H) / 65°(V)
Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Relays controlled
Individually by DTMF tones
Individually by DTMF tones
Multi-way unlock
Face, IC/ID Card, PIN, QR code and BLE
Face, IC/ID Card, PIN, QR code and BLE
Camera
Permanently operational
Permanently operational
White balance
Auto
Auto
Minimum illumination
0.1LUX
0.1LUX
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
