High-end Smart Door Phone for Luxury Buildings.
Akuvox X915 is a high-end smart Android door phone designed for luxury buildings, combining elegant style with advanced technology and premium materials. It features an 8‑inch IPS touchscreen with a sleek, ultra-narrow bezel, and a primary HDR starlight camera that delivers exceptional image quality and wide dynamic range. The device performs rapid, highly accurate face recognition and includes mask detection for secure, contact-free entry. Built with a stainless steel AISI 316 front panel and a rugged IP65/IK10-rated body, the X915 is ideal for outdoor installations. It supports multiple authentication modes—face, RFID/NFC (13.56 MHz & 125 kHz), PIN, BLE, and QR codes—and integrates seamlessly into IP-based systems via SIP and ONVIF protocols. Featuring dual starlight cameras with anti-spoofing algorithms, two-way video/audio, echo cancellation codecs (PCMU, PCMA, G722), DTMF support, standalone line-out, 3 relay outputs, Wiegand, RS485, and PoE+ or 12–24 V DC power supply—X915 delivers top-tier performance and security with sophistication and style.
Akuvox X915 is a high-end IP video doorphone designed for luxury residential and commercial properties. It features a 2MP wide-angle camera with IR night vision and supports multiple access methods, including face recognition, RFID, NFC, PIN code, BLE, and QR code. Housed in an IP65-rated aluminum-alloy body, it ensures reliable outdoor performance and integrates easily into IP systems via SIP and ONVIF. Powered by PoE+ or 12–24 V DC, X915 offers flexible and secure access control in premium environments.


Akuvox X915
X915S
X915 HID iClass
X915 HID Prox
Physical & Power
Front panel
316 grade stainless steel
316 grade stainless steel
316 grade stainless steel
Display
8 Inch IPC LCD
8 Inch IPC LCD
8 Inch IPC LCD
Main Camera
5M pixels, with starlight
5M pixels, with starlight
5M pixels, with starlight
Light sensor
Infrared Sensor
Motion Sensor
Wiegand port
RS485 port
Line Out
RF card reader
13.56MHz & 125kHz, NFC (Only Android)
HID iClass 13.56MHz
HID Prox 125kHz
Relays out
3
3
3
Inputs
3
3
3
BLE
Microphone
2
2
2
Speaker
2, 8Ω / 2W
2, 8Ω / 2W
2, 8Ω / 2W
Tamper alarm
Reset Button
1
1
1
Ethernet port
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
PoE
IEEE 802.3at PoE
IEEE 802.3af PoE+
IEEE 802.3af PoE+
Power
12~24V DC connector (if not using PoE)
12~24V DC connector (if not using PoE)
12~24V DC connector (if not using PoE)
IP & IK rate
IP66 & IK10
IP66 & IK10
IP66 & IK10
Installation
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Wall-mounted & Flush-mounted
Dimension (wall-mounted)
350x130x37.9mm
350x130x37.9mm
350x130x37.9mm
Dimension (flush-mounted)
350x130x53.9mm
350x130x53.9mm
350x130x53.9mm
Working humidity
10~90%
10~90%
10~90%
Working temperature
-40°C ~ +60°C
-40°C ~ +60°C
-40°C ~ +60°C
Storage temperature
-40°C ~ +70°C
-40°C ~ +70°C
-40°C ~ +70°C
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ
G.711a, G.711μ
G.711a, G.711μ
Wideband audio codec
G.722
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Video
Sensor
1/2.7”, CMOS for main camera
1/2.7”, CMOS for main camera
1/2.7”, CMOS for main camera
Pixels
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
CIF, QCIF, VGA, 4CIF, 720p, 1080p
Video codec
H.264
H.264
H.264
Video technology
HDR
HDR
HDR
Video resolution
up to 1920x1080
up to 1920x1080
up to 1920x1080
Max. image transfer rate
1080p – 30fps
1080p – 30fps
1080p – 30fps
Viewing angle
120°(H) / 67°(V)
120°(H) / 67°(V)
120°(H) / 67°(V)
Compatible to 3rd-Party-Video components, e.g. NVRs
Video technology
HDR
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
Android OS for any 3rd party software or customization
Relays controlled
Individually by DTMF tones
Individually by DTMF tones
Individually by DTMF tones
Multi-way Unlock
Face, Card, PIN, BLE & QR code
Face, Card, PIN, BLE & QR code
Face, Card, PIN, BLE & QR code
Camera
Permanently operational
Permanently operational
Permanently operational
White balance
Auto
Auto
Auto
Minimum illumination
0.1LUX
0.1LUX
0.1LUX
Auto- night mode with LED illumination
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Entry log export
Access table export / import
Firmware upgrade
System logs (include door access logs)
