Premium touch screen for your home
The Akuvox C316 multifunctional communicator, with an Android 12 operating
system, provides audio and video communication with door phones via SIP 2.0
protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 7-inch capacitive touch screen display.
system, provides audio and video communication with door phones via SIP 2.0
protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 7-inch capacitive touch screen display.
- Ultra-clear, stylish appearance;
- Android 12 OS；
- 7-inch capacitive touch screen with energy saving mode;
- Two-way audio communication with other units in the network;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
- Powered by PoE or external source
- Support US or European electrical wall box mounting
Residents can enjoy crystal clear audio communication with visitors as well as seeing them as if conversing face to face before remotely granting or denying access.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
???????????????????
Akuvox C316
C316S
C316W
Physical & Power
Front panel
Plastic
Plastic
OS
Android 12
Android 12
RAM/ROM
2GB / 8GB
2GB / 8GB
Display
7 Inch TFT LCD
7 Inch TFT LCD
Screen
7 Inch capacitive touch screen
7 Inch capacitive touch screen
BLE
Wi-Fi
RS485 port
Relays out
1
1
Bell in
1
1
Alarm inputs
8
8
Microphone
-58dB
-58dB
Speaker
4Ω / 2W
4Ω / 2W
Ethernet ports
2xRJ45, 10/100Mbps adaptive
2xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Installation
Wall-mounted & Desktop
Wall-mounted & Desktop
Dimension
200.2x132.2x27.2mm
200.2x132.2x27.2mm
Working humidity
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally white, Transmissive
Normally white, Transmissive
LCD Size
7inch (Diagonal)
7inch (Diagonal)
Resolution
1024x600
1024x600
Contrast ratio
800:1
800:1
Luminance
270 cd/m²
270 cd/m²
Viewing Angle
75° Left, 75° Right,
70° Upper, 75° Lower
70° Upper, 75° Lower
75° Left, 75° Right,
70° Upper, 75° Lower
70° Upper, 75° Lower
Touch Screen
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Automatic Gain Control
Video
Streaming formats
H.263 & H.264
H.263 & H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
