Smart Indoor Monitor for Residents of All Ages
The Akuvox C319S multifunctional communicator, with an Android 9.0 operating system, provides audio and video communication with door phones via SIP 2.0 protocol. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 10-inch capacitive touch screen display .
- Android 9 OS;
- 10-inch capacitive touch screen with energy saving mode;
- Built-in 1MP CMOS camera
- Reception of a HD picture from the door communicator;
- Two-way audio communication with other units in the network;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
- Powered by PoE or external source
- Support US or European electrical wall box mounting
- Built-in smart voice assistant
C319 is perfect for elderly care. It can fully integrate telecare pendants and work seamlessly with a service center, ensuring 100% emergency signal delivery.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
???????????????????/
Akuvox C319 is a 10" Android indoor monitor with smart intercom features for people of all ages, an intuitive UI that even kids learn to use quickly, the capability of integrating telecare pendants for older individuals, and a built-in voice assistant for young people.
Akuvox C319
C319S
C319W
C319A
Physical & Power
Front panel
Plastic
Plastic
Plastic
RAM/ROM
2GB / 8GB
2GB / 8GB
2GB / 8GB
Display
10 Inch IPS LCD
10 Inch IPS LCD
10 Inch IPS LCD
Screen
10 Inch capacitive touch screen
10 Inch capacitive touch screen
10 Inch capacitive touch screen
Wi-Fi
BLE
Camera
1MP camera, CMOS
Micro SD card slot
RS485 port
Relays out
2
2
2
Bell in
1
1
1
Alarm inputs
8
8
8
Microphone
-26dB
-26dB
-26dB
Speaker
4Ω / 3W
4Ω / 3W
4Ω / 3W
Ethernet ports
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Installation
Wall-mounted & Desktop
Wall-mounted & Desktop
Wall-mounted & Desktop
Dimension
251x182.5x29.75mm
251x182.5x29.75mm
251x182.5x29.75mm
Working humidity
10~90%
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally black, Transmissive
Normally black, Transmissive
Normally black, Transmissive
LCD Size
10inch (Diagonal)
10inch (Diagonal)
10inch (Diagonal)
Aspect Ratio
16:10
16:10
16:10
Resolution
1280x800
1280x800
1280x800
Contrast ratio
900:1
900:1
900:1
Luminance
350 cd/m²
350 cd/m²
350 cd/m²
Viewing Angle
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
Touch Screen
Projected capacitive
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Automatic Gain Control
Video
Streaming formats
H.263 & H.264
H.263 & H.264
H.263 & H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
Voice Assistant
Voice pickup distance
up to 5 meters
up to 5 meters
up to 5 meters
Voice recognition accuracy
up to 95%
up to 95%
up to 95%
Privacy protection with native voice data
Support English
