Premium touch screen for your home
The Akuvox S562 multifunctional communicator, with a Linux operating system, provides audio and video communication with door phones via SIP 2.0 protocol. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 7-inch capacitive touch screen display.
- Ultra-clear, stylish appearance
- 7-inch capacitive touch screen with energy saving mode
- Two-way audio communication with other units in the network
- Complies with SIP standard for easy integration in every SIP capable PBXes
- Powered by PoE or external source
- Support US or European electrical wall box mounting or surface mounting without any electrical wall box
S562 Supports integration with surveillance cameras, allowing users to stream and monitor the live footage from both door phone cameras and 3rd-party security cameras.
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs (include door access logs)
The design of a slim body decorated with linear grilles, which conceal the speaker, lends S562 a cohesive and refined look and feel.
Akuvox S562
S562/S562-S
S562W/S562W-S
Physical & Power
Front panel
Plastic
Plastic
RAM/ROM
128MB/128MB
128MB/128MB
Display
7 Inch TFT LCD
7 Inch TFT LCD
Screen
7 Inch capacitive touch screen
7 Inch capacitive touch screen
Wi-Fi
RS485 port
Relays out
1
1
Bell in
1
1
Alarm inputs
8
8
Microphone
-42dB
-42dB
Speaker
4Ω / 2W
4Ω / 2W
Ethernet ports
2xRJ45, 10/100Mbps adaptive
2xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Installation
Wall-mounted & Desktop / Surface-mounted (On-Wall)
Wall-mounted & Desktop / Surface-mounted (On-Wall)
Dimension
216.4x118.8x21.7mm / 216.4x118.8x25.5mm
216.4x118.8x21.7mm / 216.4x118.8x25.5mm
Working humidity
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally white, Transmissive
Normally white, Transmissive
LCD Size
7inch (Diagonal)
7inch (Diagonal)
Resolution
1024x600
1024x600
Contrast ratio
600:1
600:1
Luminance
250 cd/m²
250 cd/m²
Viewing Angle
50° Left, 50° Right,
40° Upper, 50° Lower
40° Upper, 50° Lower
50° Left, 50° Right,
40° Upper, 50° Lower
40° Upper, 50° Lower
Touch Screen
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
Out-of-band DTMF (RFC2833), SIP Info
Out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Video
Streaming formats
H.264
H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
