Premium Indoor Monitor for Your Home
The Akuvox S563 is an 8-inch SIP indoor monitor that runs on the Android 12 operating system. It features an exceptional speaker and a high-resolution touchscreen display, ensuring an unparalleled audio-visual intercom experience. Its stylish and space-saving design blends seamlessly into modern homes.
- Seamless compatibility with Android 12 OS
- Exceptional two-way audio communication
- Easy integration with SIP PBXes
- Powered by PoE or an external power supply
- Voice changer function to protect vulnerable individuals
- Compatible with US or European electrical wall boxes
- Built-in smart voice assistant
The Akuvox S563's Android 12 OS enables the seamless integration of third-party apps, transforming the device into a hub for smart living. Typically, a smart home app can be installed for managing security, lighting, and more. One screen, multiple uses.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
?????????????????????????
Relying on S563's front-facing speaker and a 1280 x 800 resolution display, you can immerse yourself in lifelike audio and video quality. Gain a vivid understanding of your visitors' identity. See and hear like never before.
Akuvox S563
S563
S563W
Physical & Power
Front panel
Plastic
Plastic
RAM/ROM
2GB / 8GB
2GB / 8GB
Display
8 Inch IPS LCD
8 Inch IPS LCD
Screen
8 Inch capacitive touch screen
8 Inch capacitive touch screen
BLE
Wi-Fi
RS485 port
Relays out
1
1
Bell in
1
1
Alarm inputs
8
8
Microphone
-26dB
-26dB
Speaker
4Ω / 2W
4Ω / 2W
Ethernet ports
2xRJ45, 10/100Mbps adaptive
2xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Installation
Wall-mounted & Desktop
Wall-mounted & Desktop
Dimension
216.2x124.4x22.1 mm
216.2x124.4x22.1 mm
Working humidity
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally white, Transmissive
Normally white, Transmissive
LCD Size
8inch (Diagonal)
8inch (Diagonal)
Resolution
1280x800
1280x800
Contrast ratio
1200:1
1200:1
Luminance
310 cd/m²
310 cd/m²
Viewing Angle
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
Touch Screen
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Automatic Gain Control
Video
Streaming formats
H.263 & H.264
H.263 & H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
Voice Assistant
Voice pickup distance
up to 5 meters
up to 5 meters
Voice recognition accuracy
up to 95%
up to 95%
Privacy protection with native voice data
Support English
