Premium touch screen for your home
The Akuvox S565 multifunctional communicator, with a Linux operating system,
provides audio and video communication with door phones via SIP 2.0 protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 10-inch capacitive touch screen display.
provides audio and video communication with door phones via SIP 2.0 protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 10-inch capacitive touch screen display.
- Ultra-clear, stylish appearance;
- 10-inch capacitive touch screen with energy saving mode;
- Two-way audio communication with other units in the network;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
- Powered by PoE or external source
- Support US or European electrical wall box mounting
Residents can enjoy crystal clear audio communication with visitors as well as seeing them as if conversing face to face before remotely granting or denying access.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
????????????????????
The Akuvox S565 is a 10-inch SIP video indoor monitor that runs on the Linux OS. It features a stylish industrial design and a high-resolution touchscreen display, supporting high-quality video & audio communication and is suitable for mid-range housing markets.
Akuvox S565
S565
S565W
Physical & Power
Front panel
Plastic
Plastic
RAM/ROM
128MB / 256MB
128MB / 256MB
Display
10 Inch IPS LCD
10 Inch IPS LCD
Screen
10 Inch capacitive touch screen
10 Inch capacitive touch screen
Wi-Fi
RS485 port
Relays out
1
1
Bell in
1
1
Alarm inputs
8
8
Microphone
Dual microphones
Dual microphones
Speaker
1
1
Ethernet ports
2xRJ45, 10/100Mbps adaptive
2xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Installation
Wall-mounted & Desktop
Wall-mounted & Desktop
Dimension
278x164x22.8 mm
278x164x22.8 mm
Working humidity
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally white, Transmissive
Normally white, Transmissive
LCD Size
10inch (Diagonal)
10inch (Diagonal)
Resolution
1280x800
1280x800
Contrast ratio
900:1
900:1
Luminance
350 cd/m²
350 cd/m²
Viewing Angle
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
Touch Screen
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
Out-of-band DTMF (RFC2833), SIP Info
Out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Video
Streaming formats
H.264
H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
