A smart intercom, as well as a gear for audiophile
The Akuvox S567 Indoor monitor with an Android 12 operating system, provides an unparalleled audio-visual intercom experience with four high level speakers. Automatically adjust screen brightness through environment sensing, voice assistant and Voice Changer to bring convenience and safety to your home.
- Strong compatibility with Android 12 OS;
- Completely solve the stability problem of Wi-Fi with Wi-Fi 6;
- Two-way audio communication with other units in the network;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
- Powered by PoE or external source;
- Automatically adjust the screen brightness according to the ambient brightness to protect eyes and save energy;
- Support Voice Changer to protect the children and women living alone;
- Support US or European electrical wall box mounting;
- Built-in smart voice assistant;
The high openness of Android 12 OS allows S567 to be integrated with mainstream smart home systems.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
???????????????????????/
When you are testing a new recipe, S567 is your cooking tutorial.
Akuvox S567
S567
S567W
S567A
Physical & Power
Front panel
Plastic
Plastic
Plastic
RAM/ROM
2GB / 8GB
4GB / 16GB
4GB / 16GB
Display
10 Inch IPS LCD
10 Inch IPS LCD
10 Inch IPS LCD
Screen
10 Inch capacitive touch screen
10 Inch capacitive touch screen
10 Inch capacitive touch screen
Wi-Fi
BLE
Camera
5MP
RS485 port
Relays out
1
1
1
Bell in
1
1
1
Alarm inputs
8
8
8
Microphone
Dual microphones, -26dB
Dual microphones, -26dB
Dual microphones, -26dB
Speaker
Quad speakers, 8Ω / 2W
Quad speakers, 8Ω / 2W
Quad speakers, 8Ω / 2W
Ethernet ports
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Tamper Resistant
Installation
Wall-mounted & Desktop
Wall-mounted & Desktop
Wall-mounted & Desktop
Dimension
278.5x165.1x22.8 mm
278.5x165.1x22.8 mm
278.5x165.1x22.8 mm
Working humidity
10~90%
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally black, Transmissive
Normally black, Transmissive
Normally black, Transmissive
LCD Size
10inch (Diagonal)
10inch (Diagonal)
10inch (Diagonal)
Aspect Ratio
16:10
16:10
16:10
Resolution
1280x800
1280x800
1280x800
Contrast ratio
900:1
900:1
900:1
Luminance
290 cd/m²
290 cd/m²
290 cd/m²
Viewing Angle
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
Touch Screen
Projected capacitive
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Automatic Gain Control
Video
Streaming formats
H.263 & H.264
H.263 & H.264
H.263 & H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
Voice Assistant
Voice pickup distance
up to 5 meters
up to 5 meters
up to 5 meters
Voice recognition accuracy
up to 95%
up to 95%
up to 95%
Privacy protection with native voice data
Support English
