Luxury Smart Indoor Monitor Perfect for Your Home
The Akuvox X933 multifunctional communicator, with an Android 9.0 operating
system, provides ultimate audio and video communication with door phones via SIP
2.0 protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 7-inch capacitive touch screen display.
system, provides ultimate audio and video communication with door phones via SIP
2.0 protocol.
It delivers the ultimate touch screen experience in an unobtrusive, space-saving
design featuring a brilliant 7-inch capacitive touch screen display.
- Stylish appearance from Italy ;
- Excellent performance with Android 9.0 system;
- 7-inch capacitive touch screen with energy saving mode;
- Two-way audio communication with other units in the network;
- Ultimate visual experience with 1280 x 800 resolution;
- Reception of a HD picture from the door communicator;
- Powered by PoE or external source;
- Support US or European electrical wall box mounting;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
The easy integration with home
automation systems enables you to
access both intercom and smart home features from just one screen.
automation systems enables you to
access both intercom and smart home features from just one screen.
- Automatic initialization;
- Web interface management;
- Network traffic analysis;
- Backup/restore settings;
- Firmware update;
- System log (including access log).
???????????????????
The minimalist UI features a modern design and simplified operation, which allow users to reach main functions in less than three taps.
Akuvox X933
X933
X933W
Physical & Power
Front panel
Plastic
Plastic
RAM/ROM
2GB / 8GB
2GB / 8GB
Display
7 Inch IPS LCD
7 Inch IPS LCD
Screen
7 Inch capacitive touch screen
7 Inch capacitive touch screen
BLE
Wi-Fi
RS485 port
Relays out
2
2
Bell in
1
1
Alarm inputs
8
8
Microphone
Dual microphone
Dual microphone
Speaker
Dual speaker
Dual speaker
Ethernet ports
1xRJ45, 10/100Mbps adaptive
1xRJ45, 10/100Mbps adaptive
PoE
802.3af Power-over-Ethernet
802.3af Power-over-Ethernet
Power
12V DC connector (if not using PoE)
12V DC connector (if not using PoE)
Tamper Resistant
Installation
Wall-mounted
Wall-mounted
Dimension
205x148x27.5mm
205x148x27.5mm
Working humidity
10~90%
10~90%
Working temperature
-10°C ~ +45°C
-10°C ~ +45°C
Storage temperature
-20°C ~ +70°C
-20°C ~ +70°C
Touch Screen Display
Display Mode
Normally white, Transmissive
Normally white, Transmissive
LCD Size
7inch (Diagonal)
7inch (Diagonal)
Resolution
1280x800
1280x800
Contrast ratio
1200:1
1200:1
Luminance
310 cd/m²
310 cd/m²
Viewing Angle
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
80° Left, 80° Right,
80° Upper, 80° Lower
80° Upper, 80° Lower
Touch Screen
Projected capacitive
Projected capacitive
Audio
SIP
SIP v1 (RFC2543), SIP v2 (RFC3261)
SIP v1 (RFC2543), SIP v2 (RFC3261)
Narrowband audio codec
G.711a, G.711μ, G.729
G.711a, G.711μ, G.729
Broadband audio codec
G.722
G.722
DTMF
In-band, out-of-band DTMF (RFC2833), SIP Info
In-band, out-of-band DTMF (RFC2833), SIP Info
Echo cancellation
Voice activation detection
Comfort noise generator
Automatic Gain Control
Video
Streaming formats
H.263 & H.264
H.263 & H.264
Networking & Protocol
Protocols support
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
Auto-provisioning
Web management portal
Web-based packet dump
Configuration backup / restore
Firmware upgrade
System logs (include door access logs)
Voice Assistant
Voice pickup distance
up to 5 meters
up to 5 meters
Voice recognition accuracy
up to 95%
up to 95%
Privacy protection with native voice data
Support English
