Physical & Power

Front Panel;Aluminum RAM / ROM;2GB / 16GB Display;7 Inch IPS LCD Main Camera;2M pixels, with starlight Auxiliary Camera;1M pixels (R29C version) Light Sensor;Support Infrared Sensor;Support (R29C version) Wiegand Port;Support RS485 Port;Support Line Out;Support RF Card Reader;13.56MHz & 125kHz Relays Out;3 Inputs;3 Microphone;-32dB Speaker;8Ω / 2W Bluetooth;Support (R29C version) Ethernet port;1xRJ45, 10/100Mbps adaptive IEEE Power-over-Ethernet;802.3at PoE IP & IK Level;IP65 & IK06 Installation;Flush-mounted & Wall-mounted Flush-mounted DIM;324x130x60mm Wall-mounted DIM;324x130x33mm Working Humidity;10~90% Working Temperature;-20°C ~ +55°C Storage Temperature;-40°C ~ +70°C

Audio

SIP v1 (RFC2543), SIP v2 (RFC3261);Support Narrowband audio codec;G.711a, G.711μ, G.729 Wideband audio codec;G.722 DTMF;In-band, out-of-band DTMF (RFC2833), SIP Info Echo Cancellation;Support Voice Activation Detection;Support Comfort Noise Generator;Support

Video

Sensor;1/2.8”, CMOS Pixels;CIF, QCIF, VGA, 4CIF, 720p, 1080p Video codec;H.264 Video technology;HDR Video resolution;up to 1920x1080p Max. image transfer rate;1080p – 25fps Viewing angle;105°(H) / 55°(V) Compatible to 3rd-Party-Video components, e.g. NVRs;Support

Networking & Protocol

Protocols support;IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Door Entry Feature

Android OS;for any 3rd party software or customization Relays controlled;individually by DTMF tones Multi-way Unlock; Face, IC/ID Card, PIN and BLE Camera;permanently operational Auto-night mode;with LED illumination White balance;auto Minimum illumination;0.1LUX

Deployment & Maintenance

Auto-Provisioning Web management portal Web-based packet dump Configuration backup / restore Entry log export Access table export / import Firmware upgrade System logs (include door access logs)

Application Scenario

Provides resident / visitor access control for buildings such as condominiums, apartment buildings, office buildings, gated communities and industrial buildings
